Factory Lead Time

16 Weeks

Mount

Panel, Through Hole

Mounting Type

Through Hole

Package / Case

Module

Number of Pins

10

Published

2012

JESD-609 Code

e3

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

ECCN Code

5A991.B.5.A

Connector Type

MTRJ

Terminal Finish

Tin (Sn)

Max Operating Temperature

70°C

Min Operating Temperature

0°C

Applications

General Purpose

Additional Feature

2 X 5 ARRAY, OPTICAL OUTPUT POWER FOR 62.5/125 FIBER TYPE: 0.026MW

HTS Code

8517.62.00.50

Supply Voltage

3.3V

Body Length or Diameter

49.56mm

Lead Pitch

1.778mm

Max Output Current

50mA

Operating Supply Voltage

3.3V

Supply Voltage-Max (Vsup)

3.465V

Row Spacing

10.16 mm

Output Current

50mA

Data Rate

100 Mbps

Fiber Type

50/125, MMF

Fiber Optic Device Type

TRANSCEIVER

Built-in Feature

AMPLIFIER

Operating Wavelength-Nom

1308 nm

Emitter/Detector Type

LASER DIODE, PIN PHOTODIODE

Optical Power Output-Nom

0.009mW

Communication Standard

ATM, OC-3, SDH, SONET, STM-1

Width

13.59mm

Body Height

9.8mm

REACH SVHC

No SVHC

Radiation Hardening

No

RoHS Status

ROHS3 Compliant

Lead Free

Lead Free
